HDPLEX GaN 250 is a passively cooled 250W power supply designed for ultra compact PCs. Two units can be synced together for additional wattage. The GaN 250W is priced at US$145 and is available to order on HDPLEX.com. SPECIFICATIONS MODEL HDPLEX 250W GaN ATX All-In-One DIMENSIONS 170×55×25mm (L×W×H) WATTAGE 250W (300W Peak) EFFICIENCY 94% OPERATING TEMPERATURE -10~75°C SAFETY FEATURES UVP, OVP, SCP, OPP, OTP MODULARITY Y COOLING Passive Cases that supports HDPLEX 400W DC-ATX or 200W/400W ACDC mounting will also …
Streacom BC1 Mini v2
BC1 Mini v2 is widely considered the best open testbench for ITX. It features the familiar design and form factor of the original BC1 Mini. It has however been re-designed to be more environmentally friendly, robust and functional. The BC1 Mini v2 is available for purchase via QuietPC, Streacom, and multiple other sources. SPECIFICATIONS MODEL BC1 Mini v2 DIMENSIONS 230×190×78mm (L×W×H) MATERIALS 100% AL5052 Aluminium (Heavy Duty), 100% SS304 Steel SURFACE FINISH Sandblasted 80 Grain, “White Mate”, “Black”, “Titanium” Anodising …
Noctua NH-L12 Ghost
The Noctua NH-L12 Ghost S1 Edition is 66mm tall low profile cooler with 48mm of RAM clearance and 92x25mm fan. The L12 Ghost Edition heatsink is based on original L12 design and not the newer L12S. SPECIFICATIONS MODEL NH-L12 Ghost S1 Edition DIMENSIONS 150×128×66mm (L×W×H) COMPATIBILITY Intel: 115X/1200/1700AMD: AM4/AM5 MATERIALS 4x 6mm nickel plated copper heat-pipes, copper base (nickel plated), aluminium cooling fins WEIGHT 410g (heatsink only) FANS 1x Noctua NF-B9 PWM (SSO-Bearing),300~1600RPM (+/- 10%) RAM CLEARANCE 48mm TEST SYSTEM …
SilverStone FX600
SilverStone’s FX600 is quiet, non-modular Flex ATX power supply. It’s rated Platinum by Cybenetics and includes 5 year warranty from SilverStone. SilverStone’s FX600 is rebranded ENP-7660B from Enhance Electronics and can be purchased from Amazon for around $189 US. SPECIFICATIONS MODEL SilverStone FX600 MANUFACTURER (OEM) Enhance Electronics FORM FACTOR Flex-ATX CERTIFICATION Platinum (Cybenetics) DIMENSIONS 81.5×40.5×150mm (W×D×L) WATTAGE 600W OPERATING TEMPERATURE 0°C ~ 40°C SAFETY – Over Current Protection– Over Power Protection (110~130%)– Over Voltage Protection– Under Voltage Protection– Short Circuit …
Best Small mATX Cases
These are some of the best small Micro-ATX cases currently available. We periodically update this list to reflect new cases. This is not a definitive list. DAN A3-MATX Dan A3-mATX is 26.3L in volume. APOLLO SE McPrue Apollo SE is 17.4L reference layout case. NCASE M2 NCASE M2 is 15.7L in volume. DAN C4-SFX V2 Dan C4-SFX v2 is 15.4L in volume.
Enhance ENP-7660B
ENP-7660B (Black) is 600W Platinum semi-custom FlexATX power supply from Enhance Electronics. The ENP 7660 is available in US via Velkase (VK model) and UK/EU via Overtek (UK). SPECIFICATIONS MODEL ENP7660B-03YGP MANUFACTURER (OEM) Enhance Electronics FORM FACTOR Flex-ATX CERTIFICATION 80+ Platinum DIMENSIONS 81.5×40.5×150mm (W×D×L) WATTAGE 600W OPERATING TEMPERATURE 0°C~40°C SAFETY – Over Power Protection (110~130%)– Over Voltage Protection– Short Circuit Protection– Over Temperature Protection FAN SPECIFICATIONS 40x20mm (ADDA AD0412XB-C51) 70,000 Hours MTBF CONNECTORS – 1x 4+4 PIN EPS (300mm)– 2x 6+2 …
Scythe Big Shuriken 3 Review
Scythe’s Big Shuriken 3 (Rev. B) is 67mm tall low profile cooler with comparable performance to the Noctua NH-L12 Ghost Edition. SPECIFICATIONS MODEL Scythe Big Shuriken 3 (Rev. B) DIMENSIONS L: 122 x W: 122 x H: 67mm (including 15mm fan) MATERIALS 5x copper heat-pipes & copper base (nickel plated), aluminium cooling fins COMPATIBILITY Intel: 115X/1200/1700AMD: AM4 FANS 1x Kaze Flex II Slim PWM (1800RPM) RAM CLEARANCE 39mm TEST SYSTEM Testing is carried out on BC1 Mini v2 (open testbench), …
HZMOD XQ69 (Sentry 2.0 Clone)
HZMOD XQ69 is steel Mini-ITX at 7.5L in volume. The XQ69 is a near one for one clone of the popular, yet discontinued Dr Zaber Sentry 2.0. The current revision of the HZMOD XQ69, is the v4.1. SPECIFICATIONS DIMENSIONS 323 x 69 x 339mm (L x W x H) VOLUME 7.55L (including stand) MATERIALS Galvanised Steel EXTERNAL I/O 2x USB 3.0 Type-A, Power Button (LED) MOTHERBOARD SUPPORT Mini-ITX MAX CPU COOLER HEIGHT 50mm EXPANSION SLOTS 2 MAX GPU LENGTH 320mm …
IQUNIX ZX-1
IQUNIX ZX-1 is aluminium Mini-ITX case starting 9.2L internal volume for the air cooling version and 10.6L for the liquid cooling version. Case pricing starts at US$219 and ships to most countries. Use our affiliate link and code ITX-L91 at checkout for $20 saving. IQUNIX ZX-1 AIR COOLING WATER COOLING DIMENSIONS 330 x 149 x 217mm (L x W x H) 330 x 149 x 250mm (L x W x H) VOLUME 9.2 Litres (internal) 10.6 Litres (internal) MATERIALS Aluminium …
FORMD T1
The FormD T1 is a modular Mini-ITX case under 10L in volume. FormD comes in two variants, reference and sandwich kit. Case pricing starts at US$195 for sandwich kit and is available in multiple colours. SPECIFICATIONS MODEL FormD T1 v2.1 (Sandwich Kit) OVERVIEW T1 – Sandwich Kit allows for better graphics card compatibility & more build configurations vs. reference kit. MATERIALS 1.5~15mm CNC Aluminium (anodised)1~2mm Steel (powder coated) DIMENSIONS 335×135×220mm (L×W×H) VOLUME 9.95 Litres CASE I/O Power Button, USB-C (USB-C …
