Jonsbo VR3 is 19L vertical style Mini-ITX case, with similar layout to the smaller Meshroom from SSUPD. The Jonsbo VR3 is available on Overclockers UK & CaseKing. SPECIFICATIONS CASE JONSBO VR3 DIMENSIONS 204 x 255 x 382mm (L x W x H) VOLUME 19 Litres MATERIALS Steel I/O USB Type-C (20Pin) + USB 3.0 Type-A MOTHERBOARD COMPATIBILITY Mini-ITX MAX CPU COOLER HEIGHT 70mm EXPANSION SLOTS 3 MAX GPU LENGTH 325mm MAX GPU THICKNESS 60mm RADIATORS SUPPORTED 240 / 280mm POWER …
ACAT X2
ACAT X2 is SFF aluminium mATX case at 14.2L in volume. The case can be found on AliExpress and Taobao, priced between £200~£250 (excluding import taxes / delivery charges). This is the most expensive small form factor mATX case currently available. DIMENSIONS 328 x 164 x 264mm (L x W x H) VOLUME 14.2 Litres MATERIALS Aluminium I/O N MOTHERBOARD COMPATIBILITY Mini-ITX / mATX MAX CPU COOLER HEIGHT 137mm EXPANSION SLOTS 4 MAX GPU LENGTH 313mm RADIATORS SUPPORTED 240 / …
SilverStone SG16
The SilverStone SG16 (SUGO 16) is 13L cube chassis with all steel construction. This is the updated version of the popular SG13 Mini-ITX case. The SUGO 16 can be purchased via Amazon UK / Amazon US (paid links). DIMENSIONS 280 x 200 x 232mm (L x W x H) VOLUME 13 Litres MATERIALS Steel I/O HD Audio2x USB 3.0 Type-A MOTHERBOARD COMPATIBILITY Mini-ITX / Mini-DTX MAX CPU COOLER HEIGHT 85~172mm (air coolers above 85mm are restricted to SFX PSUs only) …
Sirius T80
DIMENSIONS 331 x 150 x 216mm (L x W x H) VOLUME 10.72 Litres MATERIALS Aluminium (CNC) I/O N MOTHERBOARD COMPATIBILITY Mini-ITX MAX CPU COOLER HEIGHT 64mm EXPANSION SLOTS 2 MAX GPU LENGTH 325mm MAX GPU THICKNESS 61mm POWER SUPPLY COMPATIBILITY SFX / SFX-L CASE FANS SUPPORTED Top: 2x 120mm, Bottom: 1x 120x15mm 2.5 / 3.5” DRIVES SUPPORTED 4x 2.5″ / 2x 3.5″
XTIA XPROTO-N
Xtia Xproto-N is the new edition of Xtia’s open air Mini-ITX cases, featuring flow through design for 30 series GPUs and the ability to add water cooling support through an additional mounting bracket. The Xproto-N is priced at US$118 for the base version which excludes the PCIe riser cable. The case can also be configured with LINKUP GEN 4 PCIe riser. DIMENSIONS 160 x 190 x 345mm (L x W x H) VOLUME 10.5 Litres MATERIALS Aluminium (CNC) I/O N …
IQUNIX ZX-1
IQUNIX ZX-1 AIR COOLING WATER COOLING DIMENSIONS 330 x 149 x 217mm (L x W x H) 330 x 149 x 250mm (L x W x H) VOLUME 9.2 Litres (internal) 10.6 Litres (internal) MATERIALS Aluminium Aluminium I/O HD AudioUSB Type-C2x USB 3.0 Type-A HD AudioUSB Type-C2x USB 3.0 Type-A MOTHERBOARD COMPATIBILITY Mini-ITX Mini-ITX MAX CPU COOLER HEIGHT 70mm 55mm EXPANSION SLOTS 2 2 MAX GPU LENGTH 305mm 305mm RISER CABLE Twin Axial 170mm PCIe 3.0 x16 Twin Axial 170mm …
Lian-Li / DAN A4 H2O
DAN A4 H2O is 11L aluminium Mini-ITX case, created in collaboration with Lian-Li & DAN Cases. Prices start at US$129 for PCIe 3.0 and US$169.99 for PCIe 4.0 version. The A4 H2O is available via Newegg, CaseKing & Overclockers UK. SPECIFICATIONS DAN A4 H2O SPECIFICATIONS DIMENSIONS 326 x 140 x 244mm (L x W x H) VOLUME 11.1 Litres MATERIALS Aluminium & Steel I/O 2x HD AudioUSB 3.0 Type-AUSB 3.1 (Gen 1) Type-C MOTHERBOARD COMPATIBILITY Mini-ITX MAX CPU COOLER HEIGHT …
Lian-Li Q58
Lian Li Q58 is an aluminium Mini-ITX case at 14.5L in volume. The Q58 is priced at US$119 and £109 in the UK. DIMENSIONS 342 x 170 x 250mm (L x W x H) VOLUME 14.5 Litres MATERIALS Steel Frame Aluminium & Tempered Glass Exterior I/O HD AudioUSB 3.1 Type-C USB 3.0 Type-A MOTHERBOARD COMPATIBILITY Mini-ITX MAX CPU COOLER HEIGHT 67mm EXPANSION SLOTS 3 MAX GPU LENGTH 320mm MAX GPU THICKNESS 61mm (triple slot) RADIATORS SUPPORTED Top: 240 / 280mmBottom: …
